A PPL screenshot in the job folder is not a building permit. Harrisburg solar permit design for a Dauphin County rowhouse is a municipal plan set under the Pennsylvania Uniform Construction Code. The utility filing is a second package. Stapling an interconnection status image to the front of the drawings does not show the party wall, and it does not show where the array stops.
Athol Energy prepares those drawings. We are not the installation crew, and we are not the interconnection customer. The installer submits the building permit to the municipality. The interconnection customer submits the utility request. The sheets have to be true for both, and they are not the same PDF.
Two filings, and the screenshot is neither drawing
52 Pa. Code Chapter 75 is the interconnection rule. Section 75.32 says the interconnection customer submits the request to the electric distribution company that owns the system at the site, and the EDC must accept interconnection requests electronically. For these PPL row houses, that company is PPL. The request can be electronic. A screenshot of that request is still not a site plan, a roof plan, or a one-line.
The building permit stays a municipal submission under the Pennsylvania Uniform Construction Code. It does not merge into the PPL filing because both PDFs mention the same address. Reviewers at the municipality are looking for drawings. Reviewers at PPL are looking at the interconnection request. Give each one the document that office actually checks.
What is on the drawings is the house, the shared wall, the array, and a one-line that matches the level you are actually requesting. PPL solar interconnection is the utility track. Chapter 75 interconnection is the rule that sorts the level. Keep them next to the municipal set, not in place of it.
Harrisburg solar permit design starts at the party wall
A rowhouse shares a wall with the neighbor. A roof outline that hides the lot line makes the array look like it sits on a detached house. Draw the party wall on the site plan. Show which roof is this house. Show the neighbor side as the neighbor side.
Then dimension the array setback from that wall. Put a number on the gap between the nearest module and the party wall. A shared line with no dimension hides whether the array crosses the wall or stops short of it. The reviewer should be able to read the setback without scaling a PDF on a laptop screen.
The sheet has to show the setback the design is keeping. Do not leave the gap as a hatch labeled clear of wall. Write the distance. If the array is held back, the dimension says how far. If you cannot point to that number, the site plan is not finished, no matter how clean the PPL screenshot looks.
What else the site plan has to make obvious
Property lines enough to see the row condition. The street, so the front of the house is not a mystery. North, so the party wall is not flipped in review. The array footprint on this roof only. Modules drawn across the party wall onto the next house are a different project, and they do not belong on this permit.
The roof plan should agree with the site plan. Same array outline. Same gap at the party wall. If the roof plan pulls modules closer to the wall than the site plan shows, you have two designs. Pick one and dimension it in both places.
Level 1 only when the nameplate qualifies
Harrisburg row houses on PPL are often Level 1 if the inverter nameplate is 10 kW or less. Level 1 review is inverter-based, nameplate 10 kW or less, certified equipment. The one-line has to match that description if that is the request you are filing.
Show an inverter. Show a nameplate at or under 10 kW. Identify the equipment as certified. Title the request Level 1 only when all three are true. A one-line that shows a larger nameplate and still says Level 1 is the wrong form, even if the house is a rowhouse and the utility is PPL.
Above 10 kW, Level 1 is the wrong label. Level 2 uses an inverter, a nameplate of 2 MW or less, certified equipment, and a radial circuit or a spot network that serves only one customer. Level 2 is also the review used if Level 1 was not approved. Do not keep a Level 1 title out of habit after the nameplate outgrows it. The interconnection one-line should state the level the equipment actually supports.
The one-line and the request use the same facts
Read the one-line against the application before either file goes out. Inverter, yes or no. Nameplate, the same kilowatts in both places. Certified equipment, stated where Level 1 or Level 2 requires it. EDC, PPL, because that is the company that owns the system at these row houses. Section 75.32 puts the request with that EDC, and it requires the EDC to accept the request electronically. Call that filing the electronic interconnection request.
- Site plan with the party wall and a dimension from the array to that wall.
- Roof plan whose array outline matches the site plan.
- One-line with inverter, nameplate, and certified equipment aligned to the level.
- Level 1 only when the nameplate is 10 kW or less.
- PPL named as the EDC, matching the electronic interconnection request.
The municipal set is still a building permit
Passing the Level 1 description does not file the building permit. The municipality still needs drawings under the Pennsylvania Uniform Construction Code. A rowhouse with a correct PPL request and no site plan is half a job. A rowhouse with a pretty site plan and a one-line that disagrees with the request is the other half, still unfinished.
Build the municipal set as drawings a plans examiner can mark up. Site plan, roof plan, one-line, and the attachment layout that shows how the array sits on this roof. That attachment layout should stop at the same party-wall setback the site plan dimensions. Attachments that march into the gap you just claimed are a conflict, not a detail.
Permit design is the municipal package. Residential solar drawings fit a rowhouse when the nameplate is in the Level 1 range and the architecture is a house, not a commercial roof. Pennsylvania solar design keeps the UCC submission and the Chapter 75 request as two tracks that use one set of equipment data.
Hand off two packages that agree
Give the installer a municipal set that shows the party wall and the dimensioned array setback. Give the interconnection customer a one-line that matches a Level 1 request when the inverter nameplate is 10 kW or less, with certified equipment, addressed to PPL. If the nameplate is over 10 kW, change the level before you change the screenshot.
Do not put the PPL status image on the cover of the building set and call the permit done. The building department cannot measure a party wall from a utility confirmation page. Draw the wall. Dimension the gap. Match the one-line to the level. Then the two filings can go out on the same day without pretending they are the same document.
